主要参数 / Main Parameter
| Type | Voltage ( V ) |
No-Load | Max Efficiency | |||||
| Speed(rpm) | Current | Torque ( g.cm ) | Speed ( rpm ) | Current | Output Power | EFF ( % ) | ||
| LGBLDC-2406-001 | 6 | 5380 | 0.23 A | 90 | 4341 | 0.96 A | 4.02 W | 69.68% |
| LGBLDC-2409-002 | 9 | 5390 | 0.11 A | 75 | 4480 | 0.56 A | 3.41 W | 68.49% |
| LGBLDC-2412-003 | 12 | 8010 | 0.17 A | 112.9 | 6762 | 0.92 A | 7.85 W | 71.40% |
| LGBLDC-2424-004 | 24 | 4570 | 0.05 A | 122 | 3896 | 0.29 A | 4.88 W | 70.60% |
